Cat6 RJ45 Connectors

Cat6 RJ45 Connectors

Cat6 RJ45 connectors are precision-engineered modular plugs designed to meet the stringent performance requirements of 1000BASE-T (Gigabit) and 10GBASE-T (10-Gigabit over limited distance) Ethernet over Cat6 cabling. Unlike Cat5e connectors, Cat6 plugs feature staggered contact pins that reduce crosstalk between adjacent pairs by increasing physical separation. The two-piece design includes a separate load bar (insertion guide) that organizes the four twisted pairs into the correct staggered arrangement before insertion into the connector body. This ensures that the critical untwisted length at the termination point is minimized (typically less than 13mm), preserving high-frequency performance up to 250 MHz. The contacts are gold-plated (50 micro-inch minimum) over phosphor bronze, and the clear polycarbonate housing allows visual verification of wire insertion depth. These connectors are suitable for 23-24 AWG solid or stranded conductors with an outer cable diameter of 5.5-6.5mm. TIA/EIA-568-C.2 compliant.

• Connector Type: RJ45 8P8C Cat6 modular plug, 2-piece design (plug body + load bar/insertion guide)
• Contact Arrangement: Staggered pins (reduces crosstalk between adjacent pairs)
• Cable Compatibility: Cat6 UTP (unshielded twisted pair) 23-24 AWG
• Contact Plating: Gold-plated (50 micro-inch minimum over nickel barrier, 100 micro-inch optional)
• Contact Material: Phosphor bronze (reliable insulation piercing)
• Load Bar: Separate component, color-coded for T568A/T568B wiring schemes
• Bandwidth Rating: 250 MHz (supports Gigabit Ethernet and limited 10-Gigabit)
• Conductor Type: Solid or stranded (23-24 AWG)
• Cable Diameter Range: 5.5-6.5mm (standard round Cat6 cable)
• Standards: TIA/EIA-568-C.2, ISO/IEC 11801 Class E, RoHS compliant
• Packaging: 100, 200, or 500 pieces per bag/box
• Application: Cat6 network termination, Gigabit Ethernet installations, structured cabling, data center patching
