Double Faceplate

Double Faceplates (2-Gang / 4-Port to 8-Port)

Double faceplates (2-gang wall plates) mount onto standard dual-gang electrical boxes or low-voltage brackets and provide space for a higher density of keystone ports, typically 4 to 8 ports per faceplate. These faceplates are ideal for workstations requiring multiple network drops (e.g., data, voice, AV, and fiber connections), conference rooms, classrooms, and data center office areas. The plate is manufactured from impact-resistant ABS or polycarbonate with UV stabilizers to prevent discoloration. Multiple port cutouts (round or rectangular) accept all standard keystone jacks. Screws (color-matched) are included for secure attachment. Available in white, ivory, light almond, black, and gray.

• Type: Double-gang (2-gang) wall plate for standard dual electrical boxes (vertical or horizontal mounting)
• Port Configurations: 4-port, 6-port, or 8-port (keystone openings)
• Material: High-impact ABS or polycarbonate, UL94 V-0 rated, UV-stabilized, anti-yellowing
• Dimensions: 115mm (W) x 114mm (H) standard (4.5" x 4.5") — varies by region
• Mounting: Screw-mount to standard 2-gang electrical box or low-voltage bracket (screws included)
• Compatibility: All standard keystone jacks (RJ45, RJ11, RCA, HDMI, USB, fiber, etc.)
• Screw Finish: Color-matched screws (painted to match faceplate) or stainless steel
• Edge Profile: Rounded edges, smooth finish
• Colors: White, ivory, light almond, black, gray
• Labeling: Optional icon/text label inserts for each port (sold separately)
• Application: High-density workstation outlets, conference rooms, classrooms, executive offices, laboratory data ports
• Standards: ANSI/NEMA WD 6, UL 514C, RoHS compliant
